6-CNF-120
|
CNF series solar energy free maintenance lead-acid battery |
|||||||||||
|
|
|
|
|
|
输出方式 |
||||||
|
端子 |
连线 |
||||||||||
|
MODEL |
V |
AH |
长(L) |
宽(W) |
高(H) |
总高(TH) |
KG |
类型 |
材质 |
位置 |
截面积 |
|
12V series |
|||||||||||
|
6-CNF-4 |
12 |
4 |
90 |
70 |
102 |
108 |
1.5 |
A |
CU |
C |
1.5mm2 |
|
6-CNF-7 |
12 |
7 |
151 |
65 |
95 |
100 |
2.2 |
A |
CU |
F |
1.5mm2 |
|
6-CNF-12 |
12 |
12 |
152 |
99 |
95 |
104 |
4.0 |
A |
CU |
F |
1.5mm2 |
|
6-CNF-17 |
12 |
17 |
181 |
77 |
167 |
167 |
5.5 |
C |
CU |
D |
2.5mm2 |
|
6-CNF-20 |
12 |
20 |
166 |
126 |
174 |
181 |
6.0 |
C |
CU |
D |
2.5mm2 |
|
6-CNF-24 |
12 |
24 |
166 |
126 |
174 |
181 |
8.0 |
D |
Pb |
D |
2.5mm2 |
|
6-CNF-33 |
12 |
33 |
195 |
130 |
155 |
179 |
10 |
D |
Pb |
C |
2.5mm2 |
|
6-CNF-38 |
12 |
38 |
197 |
166 |
175 |
181 |
12.6 |
D |
Pb |
D |
4.0mm2 |
|
6-CNF-55 |
12 |
55 |
230 |
138 |
215 |
229 |
18.4 |
D |
Pb |
C |
4.0mm2 |
|
6-CNF-65 |
12 |
65 |
351 |
167 |
179 |
183 |
20.5 |
D |
Pb |
D |
4.0mm2 |
|
6-CNF-80 |
12 |
80 |
330 |
173 |
214 |
238 |
26 |
D |
Pb |
D |
6.0mm2 |
|
6-CNF-100 |
12 |
100 |
330 |
173 |
214 |
238 |
30 |
D |
Pb |
D |
6.0mm2 |
|
6-CNF-120 |
12 |
120 |
408 |
174 |
208 |
237 |
34 |
D |
Pb |
D |
6.0mm2 |
|
6-CNF-150 |
12 |
150 |
482 |
170 |
240 |
240 |
43 |
D |
Pb |
C |
10.0mm2 |
|
6-CNF-200 |
12 |
200 |
522 |
239 |
218 |
245 |
60 |
D |
Pb |
E |
10.0mm2 |
|
6-CNF-250 |
12 |
250 |
520 |
268 |
220 |
249 |
73 |
D |
Pb |
E |
10.0mm2 |
|
6Vseries |
|||||||||||
|
3-CNF-4 |
6 |
4 |
70 |
47 |
101 |
108 |
0.8 |
A |
CU |
A |
1.5mm2 |
|
3-CNF-7 |
6 |
7 |
151 |
34 |
94 |
103 |
1.4 |
A |
CU |
C |
1.5mm2 |
|
3-CNF-12 |
6 |
12 |
151 |
50 |
94 |
103 |
2.2 |
A |
CU |
C |
2.5mm2 |
|
3-CNF-100 |
6 |
100 |
195 |
170 |
207 |
232 |
15 |
D |
Pb |
A |
6.0mm2 |
|
3-CNF-200 |
6 |
200 |
323 |
178 |
226 |
255 |
29 |
D |
Pb |
A |
10mm2 |
|
2V series |
|||||||||||
|
CNF-100 |
2 |
100 |
171 |
72 |
205 |
225 |
6 |
D |
Pb |
A |
According to use requirements
|
|
CNF-200 |
2 |
200 |
172 |
110 |
329 |
351 |
13.5 |
B |
CU |
G |
|
|
CNF-300 |
2 |
300 |
170 |
150 |
328 |
351 |
19.5 |
B |
CU |
G |
|
|
CNF-400 |
2 |
400 |
211 |
176 |
329 |
367 |
28 |
B |
CU |
L |
|
|
CNF-500 |
2 |
500 |
241 |
172 |
331 |
366 |
32 |
B |
CU |
L |
|
|
CNF-800 |
2 |
800 |
410 |
175 |
330 |
365 |
55 |
B |
CU |
I |
|
|
CNF-1000 |
2 |
1000 |
475 |
171 |
328 |
365 |
65 |
B |
CU |
I |
|
|
CNF-1500 |
2 |
1500 |
401 |
351 |
341 |
378 |
98 |
B |
CU |
J |
|
|
CNF-2000 |
2 |
2000 |
491 |
351 |
344 |
383 |
132 |
B |
CU |
K |
|
|
CNF-3000 |
2 |
3000 |
712 |
353 |
341 |
382 |
198 |
B |
CU |
K |
|
Product brief:
CNF series of products can match the company according to the solar energy, wind energy, energy storage requires the use of complementary type batteries, can meet the demand of the market, on the basis of the original model of lead-acid battery for solar energy storage technology rectification after the launch of the lead-acid battery energy, improved product adapted to the solar system daily cycle charge discharge and long time. Deep cycle discharge requirements.
Product superiority:
• Environmental protection: battery sealing is good, no battery leakage, the battery formula does not contain environmental pollution and difficult to recycle antimony, cadmium and other metal materials, and truly ensure the environmental protection and safety of the battery.
• adaptability: wide range of use temperature (-30 - 50 degrees Celsius), the battery can be placed transversely, and equipped with terminals and connecting lines of two output methods, suitable for all types of installation
• Deep discharge performance: after deep discharge, recharging performance is strong, even after the discharge has not been added in time, the capacity can also be recharged 100%. It can meet the needs of high frequency and deep level discharge
• Long life: computer designed corrosion resistant lead calcium lead alloy grid, ABS corrosion resistant material and high sealing reaction efficiency ensure the long life of the battery.
• short circuit resistance: application of separators with ultra-high mechanical strength to avoid short circuits
• Low internal resistance and strong acceptance of charging
Range of use
• Small power supply: 10-100W ranging from remote power free areas, such as plateau, islands, pastoral areas, border guards and other military and civilian living electricity, such as lighting, television, radio recorders, etc..
• 3-5KW home rooftop grid connected generation system.
• photovoltaic pump: solve the no electricity area of deep well drinking, irrigation.
• traffic areas: such as the pharos, traffic / railway signal lamp, traffic warning signs / street lamp, high-altitude obstacle lamp, highway / railway wireless telephone booth unattended power station etc..
• communications / Communications: solar unmanned microwave relay stations, fiber optic cable maintenance stations, broadcast / communication / paging power systems, rural carrier telephony, photovoltaic systems, small communications machines, soldier GPS power supplies, etc..
• petroleum, marine and meteorological areas: oil pipelines and reservoir gates, cathodic protection, solar power systems, oil drilling platforms, life and emergency power supplies, marine testing equipment, meteorological / hydrographic observation equipment, etc..
• Family lamp power: such as courtyard lamp, street lamp, portable lamp, camping lamp, lamp, lamp, fishing and climbing a black light lamp, tapping lamps, energy saving lamps.
• photovoltaic power plants: 10KW-50MW independent photovoltaic power station, scenic (firewood) complementary power station, a variety of large parking stations, charging stations, etc..
• solar power construction: combining solar power with building materials enables future large buildings to be self powered
• satellites, spacecraft, space solar power plants, etc..
